Haltech Linear Position Sensor

Haltech Linear Position SensorMost commonly used as shock travel sensors, the Linear Position Sensors can also be used to measure clutch position, gearbox shaft position, differential angle, or in any application that requires linear position data. In short, these simple sensors can make your ride not just faster but also more predictable. The IP65 rating suits use both inside and outside the car.A linear potentiometer includes a slider that moves in both directions, proportionally dividing the applied voltage over its operational range thus creating a voltage output based on the position of the slider. The 0-5v signal is then received by the ECU and interpreted as “travel” measured in inches or millimeters. As well as travel we can also monitor the speed of compression and extension of the slider.What’s included:Haltech Linear Position Sensor DTM3 connectorWiring Info:Pin 1 – 5v supply Pin 2 – Output Signal Pin 3 – Sensor GroundSizing Variation Info:Below Min-Max length is the mounting eyelet spacing1/2″ Cylinder Diameter 50mm Travel = 167-217mm Min-Max length 100mm Travel = 217-314mm Min-Max length 150mm Travel = 267-417mm Min-Max length 200mm Travel = 317-517mm Min-Max length 250mm Travel = 367-617mm Min-Max length1″ Cylinder Diameter 100mm Travel = 227-327mm Min-Max length 150mm Travel = 277-427mm Min-Max length 200mm Travel = 327-527mm Min-Max length 250mm Travel = 377-627mm Min-Max length
